Motorola Edge 40

Full Specifications

Released · May 04, 2023

5.3

Read Motorola Edge 40 Review

Be the first to review this phone

I want it 0 users

I have it 1 user

I had it 0 users

Deals

$779

Popular Comparisons

The Motorola Edge 40 is most commonly compared with these phones:

Design
Dimensions	6.24 x 2.83 x 0.30 inches (~0.44 inches with camera bump) 158.4 x 72 x 7.6 mm (~11.16 mm with camera bump)
Weight	5.89 oz (167.0 g)
Materials	Back: Plastic Frame: Aluminum
Resistance	Yes; IP68
Biometrics	Optical in-screen fingerprint
Keys	Right: Volume control, Lock/Unlock key
Colors	Nebula Green, Lunar Blue, Eclipse Black, Viva Magenta

Display
Size	6.5-inch
Resolution	2400x1080px, 20:9 ratio, 402 PPI
Technology	P-OLED
Refresh rate	144Hz
Screen-to-body	90.92 %
Peak brightness	1200 cd/m2 (nit)
Features	HDR support, Ambient light sensor, Proximity sensor

PhoneArena Display Test
Bright Max (20 APL)	Untested
Bright Min	2.8 (Average)
Learn more on our PhoneArena Display Test Results page.

Hardware
System chip	Mediatek Dimensity 8020 (6 nm)
Processor	Octa-core 4x 2.6GHz Cortex-A78 + 4x 2.0GHz Cortex-A55
GPU	Mali-G77 MC9
RAM	8GB
Internal storage	256GB (UFS 3.1)
Storage expansion	not expandable
OS	Android (13)

PhoneArena Performance Test
GeekBench 6 Single	1111
GeekBench 6 Multi	3572
3D Mark High	1262
3D Mark Low	1257
Learn more on our PhoneArena Performance Test Results page.

Battery
Capacity	4400 mAh
Charging	Fast charging, Qi wireless charging
Charge speed	Wired: 68.0W Wireless: 15.0W

PhoneArena Battery Test
Battery Life Estimate:	Untested
Browsing:	14h 28min
Gaming:	Untested
Video:	8h 48min
Learn more on our PhoneArena Battery Test Results page.

Camera
Rear	Dual camera
Main camera	50 MP (OIS, PDAF) Aperture size: F1.4 Sensor size: 1/1.5" Pixel size: 1.0 μm
Second camera	13 MP (Ultra-wide) Aperture size: F2.2 Pixel size: 1.12 μm
Flash	LED
Video recording	3840x2160 (4K UHD) (30 fps)
Front	32 MP

Connectivity & Features
Bluetooth	5.2
Wi-Fi	802.11 a,b,g,n,ac,ax(Wi-Fi 6),Wi-Fi 6E Wi-Fi Direct, Hotspot
USB	Type-C, USB 2.0
Location	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Sensors	Accelerometer, Gyroscope, Compass
Other	NFC

Multimedia
Headphones	No 3.5mm jack
Speakers	Earpiece, Multiple speakers
Screen mirroring	Wireless screen share
Additional microphone(s)	Noise cancellation

Cellular
5G	Bands n1, n2, n3, n4, n5, n7, n8, n20, n28, n38, n40, n41, n66, n77, n78, SA, NSA
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 20(800 DD), 26(850+), 28(700 APT), 32(1500 L-band), 66(AWS-3)
4G (TDD)	Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 42(3500), 43
3G	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
SIM type	Dual Nano SIM

Availability
Officially announced	May 04, 2023
